35 11 000 Removing and installing complete bearing block for foot pedal

WARNING: This page is about a different variant/trim than selected.

Necessary preliminary tasks

Release screws (1) and gently press clutch master cylinder (2) to one side.

Installation:

Line remains connected.

Replace self-locking nuts.

Tightening torque 21 52 4AZ .

Fig 1: Identifying Clutch Master Cylinder And Screws

Courtesy of BMW OF NORTH AMERICA, INC.

Disconnect plug connection (1).

Remove locking clip (2) and pull out pin.

Unscrew nut (3).

Release nuts (4) and gently swivel bearing block to left and remove.

Installation:

Tighten nuts (4) before nut (3).

Replace self-locking nuts.

Tightening torque 35 11 1AZ .

Fig 2: Identifying Plug Connection, Locking Clip And Nuts

Courtesy of BMW OF NORTH AMERICA, INC.
