0496080 335206 Belt Mechanical tool

WARNING: This page is about a different variant/trim than selected.
NOTE: (Tensioning strap)
Fig 1: Identifying Belt (0496080)
G09834821Courtesy of BMW OF NORTH AMERICA, INC.
