0492396 334133 Plate Mechanical tool

WARNING: This page is about a different variant/trim than selected.
NOTE: (Shaped plate, bottom) For pulling in
Fig 1: Identifying Plate (0492396)
G09834955Courtesy of BMW OF NORTH AMERICA, INC.
