0492395 334132 Plate Mechanical tool

WARNING: This page is about a different variant/trim than selected.
NOTE: (Shaped plate, top) For pulling in
Fig 1: Identifying Plate (0492395)
G09834952Courtesy of BMW OF NORTH AMERICA, INC.
