0492394 334131 Plate Mechanical tool

WARNING: This page is about a different variant/trim than selected.
NOTE: (Shaped plate, top) For removing
Fig 1: Identifying Plate (0492394)
G09834956Courtesy of BMW OF NORTH AMERICA, INC.
