63 10 004 Adjusting headlights

NOTE: Comply with TEST PRECONDITIONS FOR HEADLIGHT ADJUSTMENT .

Adjust headlights at adjusting screws (1) and (2).

A definite allocation of adjusting screws is not possible.

  1. Adjustment screw primarily for vertical adjustment
  2. Adjustment screw primarily for lateral adjustment
    Fig 1: Identifying Headlights Adjusting Screws
    G06177801Courtesy of BMW OF NORTH AMERICA, INC.
