51 16 359 Removing and installing or replacing trim cover for glove compartment

Necessary preliminary tasks:

• Remove COMPLETE GLOVE COMPARTMENT

Release screws (1).

Detach trim cover (2) from glove compartment (3).

Fig 1: Identifying Trim Cover From Glove Compartment And Screws

Courtesy of BMW OF NORTH AMERICA, INC.
