13 62 511 Replacing intake air temperature sensor (M52TU, M54)

WARNING: This page is about a different car, the 2003 BMW 525i, 2002 BMW 525i, and 2001 BMW 525i. However, it is still accessible from the selected car via links, so may be relevant.

Turn off ignition.

Remove cover from fuel injectors.

Disconnect plug connection (1) for temperature sensor.

Fig 1: Disconnecting Temperature Sensor Plug Connection

Courtesy of BMW OF NORTH AMERICA, INC.

Press catch and withdraw temperature sensor (1) from intake air manifold.

Installation:

Check sealing ring on temperature sensor for damage, replace if necessary.

Coat sealing ring with anti-seize agent.

Fig 2: Removing Temperature Sensor From Intake Air Manifold

Courtesy of BMW OF NORTH AMERICA, INC.

NOTE: Read out fault memory of DME control unit.
Check stored fault messages.
Rectify faults.
Then clear fault memory.
