32 41 060 Removing and installing vane pump for power steering (M54)
WARNING: This page does not describe the selected car, but rather 8 other vehicles, including the 2007 BMW 530i, 2007 BMW 525i, 2006 BMW 530i, 2006 BMW 525i, and 2005 BMW 530i. However, it is still accessible from the selected car via links, so may be relevant.
IMPORTANT:
Adhere to the utmost cleanliness. Do not allow any dirt to enter the hydraulic system.
Seal off pipe connections with plugs.
After installation:
- Fill and bleed hydraulic system. See 32 13 006 Bleeding Power Steering Unit .
- Check pipe connections for leaks
Necessary preliminary tasks:
- Draw off and dispose off hydraulic fluid from fluid reservoir Observe country-specific waste-disposal regulations
- Remove front assembly underside protection. See 51 47 490 REMOVING AND INSTALLING / REPLACING FRONT UNDERBODY PROTECTION .
- Remove belt pulley
- Remove deflection pulley from alternator
- Disconnect suction and pressure lines from vane pump
Version with active front steering: disconnect plug on rear side. Unfasten screws.
Tightening torque, see 32 41 1AZ in WHEEL & TIRES - TIGHTENING TORQUES
Remove vane pump towards front.
