Passenger Compartment

WARNING: This page does not describe the selected car, but rather 12 other vehicles, including the 2010 BMW M6, 2010 BMW 650i, 2009 BMW M6, 2009 BMW 650i, and 2008 BMW M6. However, it is still accessible from the selected car via links, so may be relevant.

For location of passenger compartment front fuse holder (A41a), see Fig 1. For fuse identification, amperage and components covered, see Fig 2.

Fig 1: Accessing Passenger Compartment (A41a) & Luggage Compartment (A46) Fuse Holders

Courtesy of BMW OF NORTH AMERICA, INC.

Fig 2: Identifying Fuses In Passenger Compartment Front Fuse Holder (A41a)

Courtesy of BMW OF NORTH AMERICA, INC.
