51 34 420 Removing and installing/replacing trim on window frame of rear door (front), left or right

WARNING: This page does not describe the selected car, but rather 7 other vehicles, including the 2014 BMW X6, 2013 BMW X6, 2012 BMW X6, 2011 BMW X6, and 2010 BMW X6. However, it is still accessible from the selected car via links, so may be relevant.

Necessary preliminary tasks:

Open rear side window
Release cover on door window frame, see 51 32 160 Removing and installing/replacing housing cover on inner left or right door window frame .

Detach rubber seal (1) and rubber guide (2) from trim.

Fig 1: Identifying Rubber Seal And Rubber Guide

G04767909

Courtesy of BMW OF NORTH AMERICA, INC.

Release screws (1).

Carefully detach trim (2) towards front/top.

Installation:

Moisten rubber window seal prior to fitting with water.

Fitted foam pieces must not be damaged when trim (2) is pushed in.

Fig 2: Detaching Trim Towards Front/Top

G06212777

Courtesy of BMW OF NORTH AMERICA, INC.

Installation:

If necessary, replace faulty plastic nuts (1).

Make sure rubber window seal is correctly seated.

Fig 3: Identifying Faulty Plastic Nuts

G04791734

Courtesy of BMW OF NORTH AMERICA, INC.
