51 12 825 Removing and installing/replacing guide for rear center bumper: Notes

WARNING: This page does not describe the selected car, but rather 7 other vehicles, including the 2014 BMW X6, 2013 BMW X6, 2012 BMW X6, 2011 BMW X6, and 2010 BMW X6. However, it is still accessible from the selected car via links, so may be relevant.

Necessary preliminary tasks:

Remove rear bumper trim, see 51 12 156 Removing and installing rear bumper trim .

Release nuts (1) and (2).

Disconnect plug connection for comfort aerial/antenna (3).

Feed out holder (4) towards top.

Installation:

Tightening torque 51 12 3AZ , see 51 12 REAR BUMPER .

Fig 1: Identifying Comfort Aerial/Antenna, Nuts And Holder

Courtesy of BMW OF NORTH AMERICA, INC.

Installation:

Guides in area (A) of bracket (1) must not be damaged.
