Starting Removal:

WARNING: This page does not describe the selected car, but rather 8 other vehicles, including the 2005 BMW 745i, 2005 BMW 745Li, 2004 BMW 745i, 2004 BMW 745Li, and 2003 BMW 745i. However, it is still accessible from the selected car via links, so may be relevant.
NOTE: Coil can only be turned in one direction.
  • Make sure the wire is always situated in the guide channel of the windlass (1)
  • Fit reversible ratchet (2) on coil and tension wire
  • Start by cutting lower adhesive bead
  • Grip second wire end in special tool 51 3 270
Fig 1: Feeding Wire End Into Coil Of Windlass
G03291490Courtesy of BMW OF NORTH AMERICA, INC.
