00 2 030 Universal hydro-lifter basic unit

WARNING: This page does not describe the selected car, but rather 12 other vehicles, including the 2007 BMW 530xi, 2007 BMW 530i, 2007 BMW 525xi, 2007 BMW 525i, and 2006 BMW 530xi. However, it is still accessible from the selected car via links, so may be relevant.

In conjunction with: 00 2 040, 23 0 040, 23 0 130, 24 0 170, 24 5 300, 25 5 350, 27 1 030, 33 4 420, 51 3 280

Note: Chassis and hydraulic jack - For removing and installing rear axle carriers and transmissions Also for convertible top take-up supports E85 and E64.

Series: E12, E21, E23, E24, E28, E30, E30/C, E30TOU, E31, E32, E32/3, E34, E34TOU, E36, E36/2, E36/3, E36/5, E36/7, E36/C, E36TOU, E38, E38/3, E39, E39PL, E39TOU, E46, E46/16, E46/2, E46/3, E46/5, E46/C, E52, E53, E60, E61, E63, E64, E65, E66, E67, E83, E85, E87, E90, R50, R52, R53, RR1

Fig 1: Identifying Universal Hydro-Lifter Basic Unit

Courtesy of BMW OF NORTH AMERICA, INC.

SI number: 1 05 90(207)

Order number: 00 2 030

Universal hydro-lifter basic unit

Consisting of:

1 = 00 2 031 Adapter for transmission brackets

Note: Model series: E30, E31, E32, E34, E36

In conjunction with: 23 0 000, 24 0 130
