65 77 760 Removing And Installing (Replacing) Rear Seat Sensor

WARNING: This page is about a different car, the 2006 BMW 760Li, 2005 BMW 760Li, 2004 BMW 760Li, and 2003 BMW 760Li. However, it is still accessible from the selected car via links, so may be relevant.

WARNING: Note airbag safety instructions! Incorrect handling can activate airbag and cause injury. Refer to 72 00 ... SAFETY REGULATIONS FOR HANDLING COMPONENTS WITH GAS GENERATORS .

NOTE: Follow instructions for handling optical fibers. Refer to 61 00 ... NOTES ON HANDLING OPTICAL FIBERS .

Necessary Preliminary Tasks:

Disconnect battery negative lead and cover. Refer to 12 00 ... INSTRUCTIONS FOR DISCONNECTING AND CONNECTING BATTERY .
Remove rear seat (normal). Refer to 52 24 005 REMOVING AND INSTALLING/REPLACING REAR SEAT (NORMAL) .
Remove center seat section (comfort seat). Refer to 52 24 005 REMOVING AND INSTALLING/REPLACING REAR SEAT (NORMAL)

Release screws (1).

Installation:

Tightening torque, refer to 65 77 8AZ in AUDIO, NAVIGATION AND ANTI-THEFT - TIGHTENING TORQUES .

Make sure sensor is mounted without play.

Unlock plug connections (2) and disconnect.

Remove rear seat sensor (3).

Fig 1: Rear Seat Sensor, Plug Connections And Retaining Screws

Courtesy of BMW OF NORTH AMERICA, INC.

Replacement:

Carry out coding/programming. Refer to DIAGNOSIS PROGRAMMING/CODING .

Observe following IDC specifications:

Programming.
Coding.
Car & Key Memory.
CD "CIP".

Fig 2: Programming Equipment
Courtesy of BMW OF NORTH AMERICA, INC.
