51 16... Removing And Installing/Replacing Adapter For Roller Sun Blind On Left Or Right Rear Door

WARNING: This page is about a different car, the 2005 BMW 760Li, 2004 BMW 760i, 2004 BMW 760Li, and 2003 BMW 760Li. However, it is still accessible from the selected car via links, so may be relevant.

Necessary Preliminary Tasks:

Remove roller sun blind from fixed side window in rear door. Refer to 51 16 400 REMOVING AND INSTALLING OR REPLACING ROLLER SUN BLIND AT FIXED SIDE WINDOW OF LEFT OR RIGHT REAR DOOR .

Release screws (1).

Remove adapter (2) in direction of arrow.

Fig 1: Removing Roller Sun Blind Adapter

Courtesy of BMW OF NORTH AMERICA, INC.
