52 13 390 Removing and installing / replacing front headrest (normal/ manual)

WARNING: This page is about a different car, the 2007 BMW M6, 2006 BMW M6, 2005 BMW 645Ci, and 2004 BMW 645Ci. However, it is still accessible from the selected car via links, so may be relevant.

Move backrest back.

Move headrest (1) as far upwards as possible.

Unlock lock (2) and remove headrest (1).

Fig 1: Removing And Installing / Replacing Front Headrest (Normal/ Manual)

Courtesy of BMW OF NORTH AMERICA, INC.
