52 14 033 Removing and installing/replacing release handle on left or right front seat (normal/electric)

WARNING: This page is about a different car, the 2007 BMW M6, 2006 BMW M6, 2005 BMW 645Ci, and 2004 BMW 645Ci. However, it is still accessible from the selected car via links, so may be relevant.

Lever off release lever with screwdriver.

NOTE: To protect trim, use a suitable base (1).

Installation:

Retaining lugs on release unit must not be damaged.

Fig 1: Removing And Installing/Replacing Release Handle On Left Or Right Front Seat (Normal/Electric)

Courtesy of BMW OF NORTH AMERICA, INC.
