37 14 055 Removing and installing / replacing DYNAMIC DRIVE control unit

WARNING: This page is about a different car, the 2005 BMW 645Ci and 2004 BMW 645Ci. However, it is still accessible from the selected car via links, so may be relevant.

IMPORTANT: Read and comply with notes on protection against electrostatic damage (ESD protection).

After installation:

Replacement only: Carry out coding
Replacement/coding only: Carry out steering angle sensor adjustment/adjustment for active front steering
Carry out initial DYNAMIC DRIVE operation, refer to 37 10 001 INITIAL OPERATION WITH TEST RUN OF DYNAMIC DRIVE .

Necessary preliminary tasks:

Disconnect battery negative lead
Remove trim for instrument panel, bottom left
Remove side trim in front right footwell

Unlock plug (1) and remove.

Fig 1: Removing Plug

Courtesy of BMW OF NORTH AMERICA, INC.

Release nut (2) and nut (concealed) above control unit.

Tightening torque 2.5 N.m.

Pull out Dynamic Drive control unit towards bottom.
