32 00 ... Rear axle: wheel/chassis alignment check must be carried out after the following work
WARNING: This page is about a different car, the 2005 BMW 645Ci and 2004 BMW 645Ci. However, it is still accessible from the selected car via links, so may be relevant.
A wheel/chassis alignment check must be carried out after the following work:
- Release of following screw/bolt connections:
- Swinging arm, front/rear, to rear axle carrier
- Guide arm to rear axle carrier
- Control arm to rear axle carrier
- Replacement of following parts:
- Rear axle carrier
- Swinging arm
- Integral link
- Wheel carrier / ball joint
- Control arm
- Traction strut
