65 13 060 Removing and installing/replacing speaker (mid-range speaker, in instrument panel)

WARNING: This page does not describe the selected car, but rather 19 other vehicles, including the 2010 BMW M5, 2009 BMW M5, 2008 BMW M5, 2007 BMW M5, and 2007 BMW 550i. However, it is still accessible from the selected car via links, so may be relevant.

Necessary preliminary tasks:

Remove SPEAKER TRIM .

Release screws (1).

Remove speaker (2).

Disconnect plug connection underneath and remove speaker (2) towards top.

Fig 1: Disconnecting Plug Connection Underneath

Courtesy of BMW OF NORTH AMERICA, INC.
