52 14 415 Replacing Padding for left or right front seat (normal/electric)
WARNING: This page is about a different car, the 2005 BMW 530i, 2005 BMW 525i, 2004 BMW 530i, and 2004 BMW 525i. However, it is still accessible from the selected car via links, so may be relevant.
WARNING:
US/CND front passenger seat (with OC3 mat) only:
Seat cover must not be separated from padding.
All parts must be replaced completely and released with the diagnosis system in event of defective seat cover, seat heating, OC3 mat or padding.
NOTE:
This task is identical to replacing seat cover.
Seat with air conditioning:
Remove A/C fan from padding.
Installation:
Make sure fans have correct cable routing (1).
