52 26 085 Removing and installing/replacing backrest frame for right rear seat (through-loading system)

WARNING: This page is about a different car, the 2005 BMW 545i and 2004 BMW 545i. However, it is still accessible from the selected car via links, so may be relevant.

Necessary Preliminary Tasks:

Remove backrest cover with padding. Refer to 52 26 085 REMOVING AND INSTALLING/REPLACING BACKREST FRAME FOR RIGHT REAR SEAT (THROUGHLOADING SYSTEM) .

Replacement only:

Release all screws and remove parts:

Fig 1: Locating Backrest Frame Retaining Screws

Courtesy of BMW OF NORTH AMERICA, INC.
