51 43 201 Removing And Installing Or Replacing Trim For Roof Pillar At Front (A-Pillar), Left Or Right
WARNING: This page does not describe the selected car, but rather 9 other vehicles, including the 2013 BMW 128i, 2012 BMW 128i, 2011 BMW 128i, 2010 BMW 135i, and 2010 BMW 128i. However, it is still accessible from the selected car via links, so may be relevant.
IMPORTANT:
Risk of damage!
When working on trim panel components, make sure that the sensitive surfaces are not scratched or damaged.
Release trim (1) inwards from clips (2) and feed out from instrument panel.
Installation:
Make sure mucket (3) is correctly seated on trim (2).
Installation:
If necessary, lever out clips (1) remaining in bores.
If necessary, replace faulty clips (1).
Make sure guides (3) are correctly seated in associated mountings.
Guides (3) must not be damaged.
Position trim for front roof pillar (2) preinstalled with clips (1) on associated bores and clip into place.
