51 45 187 Removing And Installing (Replacing) Instrument Panel Trim (With Active Knee Protection), Bottom Left

WARNING: This page does not describe the selected car, but rather 9 other vehicles, including the 2013 BMW 128i, 2012 BMW 128i, 2011 BMW 128i, 2010 BMW 135i, and 2010 BMW 128i. However, it is still accessible from the selected car via links, so may be relevant.

WARNING: Read and comply with safety regulations for handling airbag modules and pyrotechnical belt tensioners. Incorrect handling can activate airbag and cause injury.

Necessary preliminary tasks:

Disconnect negative battery cable.
Remove outside cover from instrument panel trim.
Remove decorative strip from instrument panel trim.
Release cover for center dashboard (do not remove).

NOTE: Move driver's seat completely rearwards for easier removal.

NOTE: Trim panel (3) removed for purposes of clarity.

Release screws in area (1) from the rear on the airbag module. Tightening torque 72 12 07AZ . Unlock associated plug connection and disconnect.

Fig 1: Identifying Airbag Module Screw

Courtesy of BMW OF NORTH AMERICA, INC.

Release screws (1). Unclip trim panel (2) downwards at latch mechanisms (3). Installation note: Latch mechanisms (3) must not be damaged.

Fig 2: Identifying Catches, Trim And Screws

Courtesy of BMW OF NORTH AMERICA, INC.

Replacement:

Modify airbag module. See AIRBAG GENERATOR .
