51 47 161 Removing And Installing/Replacing Right Luggage Compartment Wheel Arch Trim: Notes

WARNING: This page does not describe the selected car, but rather 9 other vehicles, including the 2013 BMW 128i, 2012 BMW 128i, 2011 BMW 128i, 2010 BMW 135i, and 2010 BMW 128i. However, it is still accessible from the selected car via links, so may be relevant.

IMPORTANT: Follow instructions for handling light bulbs (interior lights) . See 63 99... INSTRUCTIONS FOR REPLACING LIGHT BULBS (INTERIOR LIGHTS) .

Necessary preliminary tasks:

Remove trim on rear apron .

Release convertible top compartment spring (1) at bottom.

Release expander rivets (2 and 3).

Partially raise partition wall panel (4) and rear window frame panel (5) in covered area.

Remove rear light cover (6).

Lever out interior light (7) and disconnect electrical plug connection.

Installation:

If necessary, replace faulty expander rivets (2 and 3).

Fig 1: Releasing Expander Rivets

Courtesy of BMW OF NORTH AMERICA, INC.

Unclip emergency release knob (1) in direction of arrow.

Detach Bowden cable (2) from emergency release knob (1).

Release expander rivets (4).

Feed out luggage compartment wheel arch trim (5) in direction of arrow and remove.

NOTE: If necessary, disconnect electrical plug connection from socket (6).

Installation:

Catches (3) on emergency release knob (1) must not be damaged.

If necessary, replace faulty expander rivets (4).
