61 35 177 Removing and installing (replacing) rain/light sensor

WARNING: This page does not describe the selected car, but rather 21 other vehicles, including the 2013 BMW 328xi, 2013 BMW 328i, 2012 BMW 328xi, 2012 BMW 328i, and 2011 BMW 328xi. However, it is still accessible from the selected car via links, so may be relevant.

IMPORTANT: Read and comply with Notes On Protection Against Electrostatic Damage (ESD Protection)!

Necessary preliminary tasks:

Version with Autobeam:

Remove Interior Rear-View Mirror

Expand two-part mirror base cover (1) by pressing from below and detach.

Feed out two-part mirror base cover (1) and remove.

NOTE: Catches of two-part mirror base cover (1) must not be damaged.

Fig 1: Identifying Two-Part Mirror Base Cover And Removal Direction

G04728234

Courtesy of BMW OF NORTH AMERICA, INC.

Disconnect plug connection (3).

Press locks (1) in direction of arrow and remove rain/light sensor (2) towards bottom.

Installation:

Do not damage optical element covered by rain/light sensor (2).

If necessary, initialize Rain/Light Sensor.

Fig 2: Identifying Plug Connections, Locks, Rain/Light Sensor And Removal Direction

G04753433

Courtesy of BMW OF NORTH AMERICA, INC.

Replacement:

Carry out Vehicle Programming/Coding
