51 22 280 Removing and installing/replacing door retainer on rear left or right door

Necessary preliminary tasks:

• Close door windows
• Remove Sound Insulation  in front area only

Release screw (1).

For tightening torque refer to 51 22 3AZ in 51 22 REAR DOOR LOCKS .

Remove seal (2).

Fig 1: Identifying Seal And Screw

Courtesy of BMW OF NORTH AMERICA, INC.

Installation:

Seal (2) must not be damaged.

Make sure seal (2) is correctly seated.

Release screws (1).

For tightening torque refer to 51 22 4AZ in 51 22 REAR DOOR LOCKS .

Fig 2: Identifying Screws

Courtesy of BMW OF NORTH AMERICA, INC.

Remove door retainer (1) via cutout (2).

Fig 3: Identifying Door Retainer And Cutout

Courtesy of BMW OF NORTH AMERICA, INC.

Installation:

Following parts of door retainer (3) must not be damaged:

1. Hinge
2. Thread
   Fig 4: Identifying Door Retainer, Hinge And Thread

   Courtesy of BMW OF NORTH AMERICA, INC.
