11 21 531 Replacing all main crankshaft bearing shells (M52 / S52 / M52TU / M54 / M56)
>>
M52 B20/M52TU B20 M54 M22
M52 B20/M52TU B20 M54 M22
NOTE:
Injection nozzles for cooling the pistons are installed in the bores of bearing seats 2 to 7.
Fig 1: Identifying Injection Nozzles
Courtesy of BMW OF NORTH AMERICA, INC.
Courtesy of BMW OF NORTH AMERICA, INC.
