51 45 135 Removing and installing/replacing speaker cover on right

Remove footwell light (1) and disconnect plug connection.

Fig 1: Removing Footwell Light
G03207120Courtesy of BMW OF NORTH AMERICA, INC.

Release all 8 screws and remove speaker cover (2).

Installation:

Install longer screws at bottom.
