51 16 ... Removing and installing/replacing center armrest sliding unit: Notes

Necessary preliminary tasks:

• Remove rear compartment fresh air grill.

Release screws (1).

Fig 1: Removing Rear Compartment Fresh Air Grill

Courtesy of BMW OF NORTH AMERICA, INC.

Version without eject box:

Open center armrest (1) and remove storage tray (2) at same time.
