51 16 080 Removing and installing or replacing sun visor and left or right counter support

Lift out sun visor.

Lift out finishers on counter support and joint and unfasten screws.

Pull lighting wire out slightly and disconnect connector.

Fig 1: Lifting Out Finishers On Counter Support
G03226441

Installation:

Perform function check on lighting.
