61 31 080 Removing and installing / replacing switch from hazard warning lights

Lever out panel and lift off.

Press down switch and remove from bottom of oddments tray.

Pull off connectors.

Fig 1: Removing Switch For Hazard Warning Lights
G03169430Courtesy of BMW OF NORTH AMERICA, INC.
