Battery in luggage compartment behind side trim panel

Remove side trim panel.

Follow instructions for disconnecting and connecting

Disconnect and cover battery negative lead.

Fig 1: Removing Side Trim Panel
G03213062

Release front side trim panel partly and fold forward.

Fig 2: Releasing Front Side Trim Panel And Folding
G03213063
