52 14 380 Removing and installing/replacing head restraint support on front seat (normal/electric), left or right: Notes

Remove rear panel on front seat backrest, refer to 52 13 198 REMOVING AND INSTALLING / REPLACING REAR PANEL ON LEFT OR RIGHT FRONT SEAT BACKREST (NORMAL/ MANUAL)  .

Move head restraint downwards to max. extent.

Remove front head restraint, refer to 52 14 390 REMOVING AND INSTALLING OR REPLACING FRONT LEFT OR RIGHT HEAD RESTRAINTS (STANDARD/ELECTRIC)  .

Snap out head restraint support (1) to left and remove downwards.

Fig 1: Snapping Out Head Restraint Support To Left
G03227079

Disconnect plug connection (1) and remove head restraint support (2).
