12 13 009 Checking ignition coils (M60, M62, S62): Installation:

Position acoustic cover and press downwards until press-stud fasteners (1 ... 4) are heard to engage.



Check profile seal (1) for damage and correct seating, replace if necessary.

Fig 1: Identifying Profile Seal
G03224821
