Clutches "E" & "F": Reassembly
- Reverse disassembly procedures, noting the following: Replace all "O" rings and seals. Lubricate all components with ATF for ease of reassembly.
- Insert diaphragm spring with curved surface facing up in clutch housing "E" and "F". Make sure all clutch plates and discs are installed in proper order.
- Connect cylinders "E" and "F" by turning housing. Collar on output shaft must protrude by distance A = approx. .394" (10 mm).
