Component Location Overview - Roof Trim Panel Lamps

Fig 1: Identifying Roof Trim Panel Lamps Components

Courtesy of AUDI OF AMERICA, LLC

1. Right Illuminated Vanity Mirror -W50-
   • Refer to LEFT/RIGHT ILLUMINATED VANITY MIRROR W49/W50, REMOVING AND INSTALLING  .
2. Front Roof Module -WX3-
   • With Left Front Reading Lamp -W65- and Right Front Reading Lamp -W66-
   • With Front Passenger Airbag -Disabled- Indicator Lamp -K145-
   • The roof module must be replaced if a component is faulty.
   • Refer to FRONT INTERIOR LAMP/READING LAMP, REMOVING AND INSTALLING  .
3. Left Illuminated Vanity Mirror -W49-
   • Refer to LEFT/RIGHT ILLUMINATED VANITY MIRROR W49/W50, REMOVING AND INSTALLING  .
4. Rear Interior Lamp -WX2-
   • with Left Rear Reading Lamp -W11- and Right Rear Reading Lamp -W12-
   • The roof module must be replaced if a component is faulty.
   • Refer to Rear Interior Lamp/Reading Lamp, Removing and Installing  .
