Starter Generator Coolant Pump

Fig 1: NO CONTENT

Courtesy of AUDI OF AMERICA, LLC

T3ay

3-Pin Connector, Black

T14u

14-Pin Connector, Black

T14ux

14-Pin Connector, Black

TML

Coupling Point in Engine/Motor Compartment, Left

V621

Starter Generator Coolant Pump

Ground Connection 1 (in Engine/Motor Compartment Wiring Harness)

382

Ground Connection 17 (in Main Wiring Harness)

655

Ground Connection on Left Headlamp

B384

Powertrain CAN Bus High Connection 2 (in Main Wiring Harness)

B391

Powertrain CAN Bus Low Connection 2 (in Main Wiring Harness)

E89

Positive Connection (30a) (in Engine Wiring Harness)

For Vehicles with Diesel Engine

Refer to Applicable Engine Wiring Diagram

For Vehicles with Gasoline Engine

Depending on Equipment
