Automatic Transmission Control Module Fuse

Courtesy of AUDI OF AMERICA, LLC

J393

Comfort System Central Control Module

S113

Automatic Transmission Control Module Fuse

SC

Fuse Panel C

SC6

Fuse 6 (On Fuse Panel C)

SM

Fuse Panel M

SM9

Fuse 9 on Fuse Panel M

SC12

Fuse 12 (On Fuse Panel C)

T32i

32-Pin Connector, Naturally Cloudy, Black

B273

Positive Connection (15) (in Main Wiring Harness)

B303

Positive Connection 7 (30) (in Main Wiring Harness)

*

Refer to Applicable Wiring Diagram for Fuse Positions
