Selector Lever, Parking Lock Actuator

Courtesy of AUDI OF AMERICA, LLC

E313

Selector Lever

E816

Parking Lock Button

J587

Selector Lever Sensor System Control Module

T8x

8-Pin Connector, Black

T10ag

10-Pin Connector, Black

T10x

10-Pin Connector, Black

V682

Parking Lock Actuator

Y5

Selector Lever Transmission Range Display

687

Ground Connection 1 on Center Tunnel

825

Ground Connection 18 (in Interior Wiring Harness)

826

Ground Connection 19 (in Interior Wiring Harness)

B236

Positive Connection 6 (30a) (in Interior Wiring Harness)

*

Through June 2022

*2

From June 2022
