Spoiler, Removing And Installing, Sedan: Installing
WARNING: This page is about a different car, the 2023 Audi S3, 2023 Audi RS 3, 2023 Audi A3 Quattro, and 2023 Audi A3. However, it is still accessible from the selected car via links, so may be relevant.
- The vehicle and the spoiler must be at room temperature.
- The adhesive surfaces must be free of dirt and grease.
-- Remove the adhesive residue from the body.
-- Clean the contact surface for the spoiler on the rear lid using Cleaning Solution.
-- If equipped: cut off the retaining tabs -2- so they are level with the surface -arrow-.
- Tab overhang -1- a maximum of -a- = 0.5 mm.
-- Position the spoiler -2- on the rear lid with help from a second technician and even it out at the sides.
- The bottom side of the spoiler must be flush with the edge on the rear lid -arrow-.
- The spoiler must be centered on the rear lid: dimension -x- = equal distance to the left and right.
-- Remove the protective film using the removal aids -1 and 4-.
-- Remove the protective film sideways using the removal aids -3 and 5-.
-- Using the Roller:T40400 , press the entire length of the spoiler onto the inside (direction of travel in the front), working from the inside outward.
- Resting time approximately 30 minutes at room temperature
- It is durable after at least 24 hours.
