Outer Instrument Panel Vent, Removing And Installing, Driver Side: Removing
WARNING: This page is about a different car, the 2023 Audi S3, 2023 Audi RS 3, 2023 Audi A3 Quattro, and 2023 Audi A3. However, it is still accessible from the selected car via links, so may be relevant.
-- Move the steering wheel as far to the rear and down as possible. Use the full steering column adjustment range for this.
TIP:
The vent has a hole on both sides for attaching the Hook Tool:T40207 .
-- Carefully insert the Hook Tool:T40207 between the slats and hook it into the side of the vent.
-- Remove the vents -1- on both sides in stages, alternating from side to side -arrow-.
