Overview - Rear Glass Panel, A6 AVANT
WARNING: This page is about a different car, the 2024 Audi S6 and 2024 Audi A6 Quattro. However, it is still accessible from the selected car via links, so may be relevant.
- Bolt
- Tightening Specification. Refer to OVERVIEW - SUNROOF SHADE, FRONT, A6 .
- Sunroof Shade Frame
- Overview. Refer to OVERVIEW - SUNROOF SHADE, FRONT, A6 .
- Right Seal
- For the rear glass panel
- Mounted on the rear glass panel
- Rear Glass Panel
- Always replace after removing
- Removing and Installing. Refer to REAR GLASS PANEL, REMOVING AND INSTALLING, A6 AVANT .
- Adjusting. Refer to GLASS PANEL, ADJUSTING .
- Rear Seal
- For the rear glass panel
- Mounted on the rear glass panel
- Left Seal
- For the rear glass panel
- Mounted on the rear glass panel
