Left Rear Door Contour Illumination Lamp
J386
Driver Door Control Module
J387
Front Passenger Door Control Module
J927
Passenger Side Rear Door Control Module
L253
Left Rear Door Contour Illumination Lamp
T4bs
4-Pin Connector, Brown
T19c
19-Pin Connector, Black
T19e
19-Pin Connector, Black
T20f
20-Pin Connector, White
T20g
20-Pin Connector, White
T20t
20-Pin Connector, White
T21a
21-Pin Connector, Black
T21b
21-Pin Connector, Black
T21c
21-Pin Connector, Black
T21d
21-Pin Connector, Black
TTHR
Right Rear Door Coupling Point
TTVL
Left Front Door Coupling Point
TTVR
Right Front Door Coupling Point
1209
Ground Connection (in Driver Side Rear Door Wiring Harness)
R114
Ambient Lighting Connection (in Left Rear Door Wiring Harness)
*
For Vehicles with Ambient Lighting, Version 2
