Overview - Seat Pan Cover And Cushion, Super Sport Seat
WARNING: This page is about a different variant/trim than selected.
- Seat Cushion with Seat Depth Adjustment
- Refer to SEAT DEPTH ADJUSTER SEAT CUSHION, REMOVING AND INSTALLING
- Versions with seat heating: attach a new heating element when replacing. Refer to SEAT HEATING ELEMENT, REMOVING AND INSTALLING, SEAT DEPTH ADJUSTER .
- Seat Bolster Cushion
- Refer to SEAT PAN SEAT BOLSTER CUSHION, REMOVING AND INSTALLING, SUPER SPORT SEAT
- Versions with seat heating: attach a new heating element when replacing. Refer to SEAT HEATING ELEMENT, REMOVING AND INSTALLING, SEAT BOLSTERS .
- Molding
- Sewn into cover
- For engaging the cover to the seat pan upper frame
- Make sure it fits correctly in the seat pan upper frame
- Seat Cover
- Cover with Cushion, Removing and Installing. Refer to SEAT PAN COVER AND CUSHION, REMOVING AND INSTALLING, SUPER-SPORT SEAT .
- Cover and Cushion, Separating. Refer to SEAT PAN COVER AND CUSHION, SEPARATING .
- Check that there are no folds after installing
- Upholstery Clip
- For securing the cover to the cushion
- Replace after removing
- Install at the same location with Upholstery Clip Pliers:V.A.G 1634 .
- Seat Cushion
- Cover with Cushion, Removing and Installing. Refer to SEAT PAN COVER AND CUSHION, REMOVING AND INSTALLING, SUPER-SPORT SEAT .
- Cover and Cushion, Separating. Refer to SEAT PAN COVER AND CUSHION, SEPARATING .
- Versions with seat heating: attach a new heating element when replacing. Refer to SEAT HEATING ELEMENT, REMOVING AND INSTALLING, SEAT CUSHION .
- Seat Bolster Cushion
- Refer to SEAT PAN SEAT BOLSTER CUSHION, REMOVING AND INSTALLING, SUPER SPORT SEAT
- Versions with seat heating: attach a new heating element when replacing. Refer to SEAT HEATING ELEMENT, REMOVING AND INSTALLING, SEAT BOLSTERS .
