Overview - Rear Child Seat Anchors, A5 Cabriolet
WARNING: This page is about a different variant/trim than selected.
- Child Seat Anchor Guide
- Quantity: 4
- Refer to LOWER CHILD SEAT ANCHOR GUIDE, REMOVING AND INSTALLING
- Must be secure on the anchor
- Child Seat Anchor Cover
- Quantity: 4
- Refer to LOWER CHILD SEAT ANCHOR GUIDE, REMOVING AND INSTALLING
- Must be secure on the anchor
- Bolt
- 6.5 Nm
- Rear Seat Backrest
- Child Seat Anchor Cover
- Quantity: 2
- Refer to REAR SEAT BACKREST UPPER CHILD SEAT ANCHOR COVER, REMOVING AND INSTALLING, A5 CABRIOLET
- Can only be installed in one position
- Child Seat Anchor
- Bolt
- 6.5 Nm
- Child Seat Anchor Cover
- Quantity: 2
- Refer to REAR SEAT BACKREST UPPER CHILD SEAT ANCHOR COVER, REMOVING AND INSTALLING, A5 CABRIOLET
- Replace the damaged cover.
- Press on until it engages audibly
- Can only be installed in one position
- Backrest Frame
- Child seat anchor is welded to the backrest frame
