Component Location Overview - Infotainment System, From Product Improvement
WARNING: This page is about a different variant/trim than selected.
- Front Information Display Control Head -J685-
- Screw tightening specification: 3 Nm
- Inside the center of the instrument panel
- Refer to the appropriate Wiring Diagram
- Removing and Installing. Refer to INFOTAINMENT SYSTEM DISPLAY, REMOVING AND INSTALLING, FROM PRODUCT IMPROVEMENT .
- Information Electronics Control Module 1 -J794-
- Bracket screw tightening specification: 3 Nm
- Behind the glove compartment
- Refer to the appropriate Wiring Diagram
- Removing and Installing. Refer to Information Electronics Control Module 1 -J794-, REMOVING AND INSTALLING .
- Driver Volume Control -E67-
- Screw tightening specification: 2 Nm
- In the center console
- Removing and Installing. Refer to Driver Volume Control -E67-, REMOVING AND INSTALLING .
