Overview - Rear Water Drain Hoses, A5
WARNING: This page is about a different variant/trim than selected.
- Grommet
- Equipped on some models
- Push all the way into the body using a soap solution
- Rear Water Drain Hose
- Equipped on some models
- Cleaning. Refer to WATER DRAIN HOSES, CLEANING .
- Removing and Installing. Refer to REAR WATER DRAIN HOSES, REMOVING AND INSTALLING, A5 .
- Mount
- Equipped on some models
- For the water drain hose
- Replace after removing
- Pay attention to the allocation: left gray, right red
- Removing and Installing. Refer to REAR WATER DRAIN HOSES, REMOVING AND INSTALLING, A5 .
- Coupling Piece
- Equipped on some models
- Attach to the connection
- Clip
- Equipped on some models
- For the water drain hose
