Overview - Engine Compartment Lid
WARNING: This page is about a different variant/trim than selected.
- Tension Spring
- Quantity: 2
- Removing and Installing. Refer to TENSION SPRING, REMOVING AND INSTALLING .
- Rear Lid Hinge Trim Panel
- Removing and Installing. Refer to OVERVIEW - REAR LID LOWER TRIM PANEL .
- Stop Buffer
- For the rear lid hinge
- Hinge
- Removing and Installing. Refer to HINGE, REMOVING AND INSTALLING, A4 SEDAN AND A5 COUPE .
- Bolt
- Quantity: 4
- 21 Nm
- Nut
- Quantity: 2
- 21 Nm
- Adjusting Buffer
- Removing and Installing. Refer to ADJUSTING BUFFER, REMOVING AND INSTALLING, A4 SEDAN, A5 COUPE AND A5 CABRIOLET .
- Adjusting. Refer to HEIGHT, ADJUSTING USING ADJUSTING BUFFER .
- Stop Buffer
- Body
- Rear Lid
- Removing and Installing. Refer to REAR LID, REMOVING AND INSTALLING, A4 SEDAN AND A5 COUPE .
- Adjusting. Refer to REAR LID, ADJUSTING .
- Ball Pin
- 21 Nm
- Ball Pin
- 21 Nm
- Gas-Filled Strut
- Only on the right side of the vehicle
- Removing and Installing. Refer to GAS-FILLED STRUT, REMOVING AND INSTALLING .
- Stop
- On the lid side
- Removing and Installing. Refer to ADJUSTING BUFFER STOP, REMOVING AND INSTALLING, A4 SEDAN AND A5 COUPE .
- Stop
- On the body side
- Removing and Installing. Refer to ADJUSTING BUFFER STOP, REMOVING AND INSTALLING, A4 SEDAN AND A5 COUPE .
- Rear Lid Seal
- Removing and Installing. Refer to the appropriate Service Information .
- Nut
- Quantity: 2
- 21 Nm
- Adjusting Buffer
- Removing and Installing. Refer to ADJUSTING BUFFER, REMOVING AND INSTALLING, A4 SEDAN, A5 COUPE AND A5 CABRIOLET .
- Adjusting. Refer to HEIGHT, ADJUSTING USING ADJUSTING BUFFER .
